Multi-Touch Interactive Panel

Four-Touch Detection

By using the accurate infrared optical sensor technology, our Multi-touch Interactive Panel supports up to four users, regardless of using fingers or styluses, to write and draw simultaneously. With the four-color-pen mode, four users can proceed writing and drawing with different colors at the same time.

Advanced Software

With our Interactive Touch software, you could tailor-make your lectures or presentations effortlessly with the below functions:

  • Hand writing recognition
  • Geometric recognition
  • Fluorescent pen
  • Plug-and-play
  • Image saving to library
  • Content searching in library
  • Google image search
  • Advanced toolbar customization
  • Slide rotation and rearrangement
  • Page zoom in/ out
  • Data management
  • Support standard IWB format
  • Multi-touch Interactive Panel

    Stands

      We provide two types of stands according to your different requirements.
    • Standard Mobile Stand
      Interactive Panel can be mounted on it with a fixed height.
    • Electric Mobile Stand
      You could adjust the height of the Interactive Panel with ease with a remote control
    Multi-touch Interactive Panel

    Built-in Computer System

    You could also order the our Panel with a built-in Intel i5 Computer System for all-in-one solution.

    CPU RAM HARDDISK NETWORK
    Intel i5 3.1GHz 8GB DDR3 1600MHz 500GB Dual Channel Wi-Fi

    Document Camera

    You can use it to capture or project objects’ images on the Interactive Panel to your audiences and the images can be saved for further usage.

    Model 55" 65" 70" 84"
    TOUCH SENSOR
    Touch Detection Infrared LED
    Touch Tool Finger / Solid Objects
    Touch Object >4mm
    Touch IR Wavelength 850nm
    Touch Resolution 9600 x 9600
    Touch Accuracy ± 1.5mm
    Touch Response Time 8-12ms
    Touch PC Interface USB 2.0 (Full Speed) HID Compliant (Plug & Play)
    Glass Surface Anti-glare; Anti-scratch AG Tempered Glass (4-5mm)
    Touch Power Consumption 5V, < / =250mA
    Touch Operating Temperature -5°C - 50°C
    Touch Supported OS Windows 8, Windows 7, Vista, XP, Mac, Linux
    PANEL
    Diagonal Size 55" 65" 70" 84"
    Display Resolution 1920 x 1080 1920 x 1080 1920 x 1080 QWUXGA (3840 x 2160)
    Display Frame Rate 60Hz 60Hz 120Hz 120Hz
    Response Time 6ms(GTG) 6ms(GTG) 8ms(GTG) 5ms(GTG)
    Brightness(Average) 350cd/m² 350cd/m² 350cd/m² 350cd/m²
    Contrast Ratio 1400:1(Typ.) 4000:1(Typ.) 4000:1(Typ.) 1600:1(Typ.)
    Supported Colors 10bit(D) 1.06 Bi Colors 10bit(D) 1.06 Bi Colors 10bit(D) 1.06 Bi Colors 10bit(D) 1.06 Bi Colors
    Viewing Angle H: 145° / V: 145° (CR >/=10)
    Operating Temperature -5°C - 40°C, 20%-80% RH(No Condensation)
    Storage Temperature -20°C - 60°C
    SIGNAL CONNECTIVITY
    PC Connector VGA / HDML
    Audio Line Out x1; Mic In x1
    ELECTRICAL
    Power Supply Input 100 - 240V AC, 50/60Hz
    Normal Operation 140W 260W 160W 420W
    Standby < 1W < 1W < 1W < 1W
    Speakers 10W + 10W Stereo (8-ohms)
    MECHANICAL
    System Dimensions 1280 x 755 x 70mm 1541 x 911 x 70mm 1602 x 938 x 70mm 1938 x 1130 x 70mm
    Box Dimensions 1420 x 880 x 230mm 1682 x 1036 x 230mm 1750 x 1105 x 260mm 2010 x 1300 x 260mm
    Weight 55kg 65kg 75kg 96kg
    VESA Mount 400 x 400mm 400 x 400mm 400 x 400mm 600 x 400mm
    OSD FUNCTIONS
    OSD Control Function IR Remote Controller
    OSD Languages English/ French/ Dutch/ German/ Russian/ Turkish/ Swedish/ Polish
    Remark: For 84” Multi-touch Interactive Panel, only English is available
